YAMAHA YXZ 1000 RADIATOR DIRECT FIT

Stock Location Rad

The Yamaha YXZ 1000 Replacement radiator takes your YXZ a step up in performance and reliability, while utilizing the stock mounting location and fans. Featuring a 38mm core and 6mm fin, you get a massive 20% gain in coolant capacity. Also, by utilizing a triple pass design that allows coolant to pass through the radiator 3 times, we have seen temperature drops of as much as 20 degrees during testing in the most demanding conditions.

Part # Dimensions Thickness w/Fans Coolant Filler Inlet/ Outlet Fans CFM’S Core Style Oil Cooler Application
CBR6061  18.5″x15.5″x1.75″ N/A YES  7/8″ N/A  N/A 38mm Triple pass N/A 2016-… YAMAHA YXZ 1000

YAMAHA RHINO STAGE 1 & 2 COOLING KIT

The oven brazed core features a 5.4mm fin height, 58mm thickness, and a 25% larger coolant capacity, compared to the stock radiator design, a 9.8mm fin height and 26mm thickness. What separates this kit from the rest is the CBR AIR REED SHROUD, which allows more air flow to pass through the radiator the faster you go for maximum performance. Combined with a high performance 780cfm Spal fan, it is all the cooling you will need. To maximize the cooling efficiency of this kit, we have included a19mm, 23 row, all aluminum oil cooler which has doubled the surface area from the stock cooler. Oil temperatures have dropped as much as 40 degrees compared to stock. All brackets and hardware are included in the kit.

Part # Dimensions Thickness w/Fans Coolant Filler Inlet/ Outlet Fans CFM’S Core Style Oil Cooler Application
CBR7058 17 1/2 X 9 1/2 X 2 3/4 N/A Small 1” N/A N/A 58mm No 04-07 Yamaha Rhino 450/660 Radiator only
CBR7059 17 1/2 X 9 1/2 X 2 3/4 5 1/2” Small 1” (1) 9” Spall 780 58mm No 04-07 Yamaha Rhino 450/660 Stage I Kit
CBR7060 17 1/2 X 9 1/2 X 2 3/4 5 1/2” Small 1” (1) 9” Spall 780 58mm Yes 04-09 Yamaha Rhino 450/660/700 Stage II Kit
